MTV

Medium Tactical Vehicle 4×4

Download datasheet

ENGINE and POWER TRAIN

Diesel Engine with turbocharger and intercooler with high performance water cooling system for desert conditions

Rating: up to 300 HP
Torque: up to 1100 Nm

6 or 9 speed manual transmission or 6 speed fully automatic transmission
2-speed transfer case with
full time four-wheel drive
100 % locking differentials
in transfer case, front- and rear axl

SUSPENSION and STEERING

Front and rear leaf springs with
heavy duty telescopic shock
absorbers and anti-roll bars
Hydraulic Power Steering

WEIGHT, DIMENSIONS and CAPACITIES

GVW: up to 14000 kg
Fuel tank: 400 l
Wheel Base: 3460 mm, up to 4600 mm
Cabin variants: 2 door Military cabin with observation hatch or 4 door double cabin

ELECTRIC SYSTEM

24V waterproof
EMI & RFI protected
Convoy Lights
Battery master switch
NATO- charging and jump start socket
Driver monitor system for vehicle functions

PERFORMANCE

Speed: up to 120 km/h
Range: up to 1000 km
Gradeability: up to 70 %
Side slope: up to 30 %
Fording: 800 mm, w/o preparation

BRAKE SYSTEM

Dual-circuit compressed air brakes acting on the front and rear wheels with Anti-lock Braking System and semi automatic Engine Exhaust Brake system

Get in touch with STI Medium Tactical Vehicle

Contact us

SPECIAL FEATURES and OPTIONS

  • Fitted for Radio (FFR)
  • GPS Installation
  • Camouflage System
  • STIS (STEYR Tire Inflation System)
  • Run-Flat for wheels
  • Heavy Duty A/C System
  • Recovery Winch
  • Mission oriented body variants
    • Troop and Cargo Platform
    • Fuel and Water Tanker
    • Workshop Van
    • Command Post Shelter
    • Fire Fighting Vehicle
    • Recovery Sliding Platform
    • Spare Parts Transporter
    • Mobile Pharmacy
    • Refrigerator and Freezer Units
    • Tire repair unit
    • 3-way Dump Body
    • Maintenance and Lubrication units
    • Mobile Power Generator units
    • EOD units
